Step I Remove the overow lter by pulling it
forward.
Step II Wash off the lint stuck on the overow lter
during overowing.
Step III Re-x the overow lter by rst inserting
its bottom section and then pushing the upper
part rmly into the socket.
Lint Filter
Note: If during washing, some residue or deposits have accumulated in the net, then after
nish washing, remove the lter by rst push down and pull it out.
INSTALLATION
Location & Environment
Electrical Connection
*
*
*
*
Do not place the washer in steamy rooms or where the washer is directly exposed to rain.
Moisture may destroy the electrical insulation and cause an electric shock hazard.
Place washer on a sturdy at surface. If the washer is placed on an uneven or weak surface,
noise or vibrations may occur. (Allowable inclination is max. 2 degrees).
Avoid direct sunlight or heating device. As plastic and electrical components are affected by direct
heat. Never place the washer near heater, boilers etc.
Do not place or store the washer below 0
O
C (32
O
F) to avoid any damage from freezing.
*
This unit is designed to operate from an adequate supply mentioned at the rating label sticked to
the rear of it.
Caution: If the power cord is damaged, it should be replaced by a repair shop appointed by the
manufacturer, because special purpose tools are required.
HOW TO WASH
*
*
*
Sort the clothes into groups-white, colorfast, non-colorfast, delicates, lint free, lint producer, etc., and
wash according to the LAUNDRY GUIDE. (See Laundry Guide).
Clothes with worn or torn patches should rst be mended. Empty out all pockets and close all side
fasteners. (pocket, covers, belts, etc). Treat bad stains prior to washing.
Insert power cord plug into the power point and switch on.
Preparation
03
1. Set the wash timer knob to position “0”.
2. Select the wash action to the desired position.
3. Open the water faucet and feed water to the water level indicated inside the wash tub.
4. Put detergent and laundry into the wash tub.
5. Set wash time by the wash timer.
How to Wash
LAUNDRY GUIDE
Washing Time & Wash Action Table
Extremely soiled heavy fabric
Linen, cotton, etc.
Ordinary clothes (underwear, etc.)
Slightly soiled synthetic ber
100% wool, mixed wool knitting, thin synthetic
ber with tags indicating hand washing
10-15 minutes
8-10 minutes
7 minutes
2-5 minutes
2-5 minutes
KIND OF CLOTHING
WASHING TIME
CLEANING AND MAINTENANCE
At the end of every washing:
Switch off the electricity.
Ensure that timer knob reached back to “0” position.
Wipe off spillage (detergent powder, etc.) and generally wipe over the tub and base with a dry duster.
Note: Cleaning after use will extend the life of your washing machine. Before cleaning
disconnect the power cord from the electrical outlet.
HOW TO RINSE
1. Set the wash action to the (“STRONG or NORMAL”) position.
2. Turn the water tap on.
3. Place the cover ow hose at on the oor.
4. When the rinsing water becomes clear, turns off the water tap.
5. When rinsing is nished drain the wash tub by placing the drain hose
at on the oor.
02
SPECIFICATION
Model No. DW 6100 W
Intended use
Type of appliance
Power source
Dimension (units: mm)
Appliance weight
Rated operating time
Protection against electric shock
Protection against moisture
Standardized water consumption
Household
Single Tub
Refer to specication LABEL
530 x 470 x 980
16 Kg
WASHING 1 HOUR
Class 1 appliance
Splash-proof appliance
H：88.1
M：77.3
L： 54.3
Design and specications could be changed without notice.
Control Panel
1. Water Inlet
Connect the hose from the water faucet to feed water to the tub.
2. Wash Timer
Used to select the desired time for washing or rinsing.
