1 101408 Piston Block 1
2 101381
Port Plug - 7/16-20
1
3 101372
Piston Spring
1
4
101445
Piston
1
5
101355
014 Disogrin O-Ring
2
Item Part Number Description
Qty
Piston Block Assembly (101478)
1
5
2
5
3
4
1
102094
Dump Block W/Cavity
1
2 102093
Dump Block Cartridge Insert
1
3 114B70
114 Buna-N O-Ring
2
4 114TBUSP
114 Teflon Backup Ring
2
5
91255A194 8-32 x 1/2 BHCS 2
6 101374
Dump Valve Spring
1
7
102097
Dump Valve Pin
1
8 98420A134
3/8 Heavy Duty Retaining Ring
1
9 101427
Plunger Piston
1
10 214B70
214 Buna-N O-Ring
1
11
101407
Dump Block Cap
1
12
122B70
122 Buna-N O-Ring
1
13 90272A242 10-24 x 1/2 Pan Head Screw
4
14
50785K44
3/8 NPT Elbow Fitting
1
15 102250
3/8 NPT Return Nipple
1
Dump Block Assembly (101443)
ITEM PART NUMBER DESCRIPTION
QTY
1
2
5
14
15
11 12
910
8
7
6
4
3
4
13
COMPONENT PARTS BREAKDOWN
