Days Strider MD 3 - Adjusting the Seat Height - Clamping Bolt Removal

20
Issued: 24.02.2005
STRIDER MD
Adjusting the seat height
Pull the clamping bolt (3) with the form
shim (5) out of the seat support (6).
➨
Removing the clamping
bolt
Adjusting the seat height:
Tools required:
2 x ring spanner, size 12 mm
Hold the clamping bolt (3) with a ring
spanner (size 12 mm) and unscrew the
self-locking nut (4) with the other ring
spanner (size 12 mm).
➨
Remove the rear panelling.➨
Press the locking device (a) on the
plug and disconnect the electric cable
connecting plug (2) to the rear lights
and rear indicators.
➨
