Raider Mini 90 (single/double-seat): Service Manual Version：2.0 Feb. 2006
45
2. Replace Battery Box Cover
a) Assemble the battery + /－ electrode;
b) Put the battery into the battery box;
Tel.: (8
c) Put on the plastic battery box cover (part no.
50320-BDD0-0000), or add one rubber
pad in the steel battery box cover;
f) Put the battery band on the battery, and
fasten the band;
+ Electrode
－ Electrode
Battery
Battery Box
Plastic Battery Box Cover
Battery Band
To Next Page
