SERVICING
14
REMOVAL OF BURNER
Turn off gas and electrical before attempting any service to this appliance. Heater may be serviced by
following instructions below:
a. Remove the four screws on the control service panel.
b. Remove the hex nut that is holding the orifice fitting to the infrared burner’s bracket.
c. Remove the burner windscreen by removing the screw on the windscreen’s frame. Then pull
the windscreen down and slowly slide it out.
d. Remove the collector box, then loosen both screws on the igniter and the electrode sensor.
e. Last, pulling infrared burner out of the heater, extreme care should be taken. To prevent the
burner from contacting the fragile electrode sensor or the igniter when removing or
reinstalling the burner. Unscrew the four screws that are holding the infrared burner to the
burner and channel baffles. Remove the four screws holding the burner in place. Be careful
not to let the burner fall out.
f. Lift up the left side of the infrared burner by the burner channel and slide it out of the heater.
g. To reinstall burner, reverse procedure.
