DCS DCS-DRH48N - Wiring Diagram

WIRING DIAGRAM
18
120 VAC 60 Hz
120 VAC 60 Hz
24 VAC
Ground
MINI IGNITER
NOTE: 1. PURPLE, FLAME SENSE (ELECTRODE SENSOR) 2. GREEN, GROUND 3. BLUE, TO VALVE HOT (LOCATION 1) 4. ORANGE, THERMOSTAT 5. KEY 6. BLACK, L1-24 VAC 7. RED IGNITER
ELECTRODE SENSOR
969 FIG09.EPS
Valve
2
1
3
4
6
2
17
IGNITION MODULE
