INSTALLATION
MINIMUM CLEARANCES TO COMBUSTIBLE MATERIAL.
CLEARANCES/INSTALLATION SPECIFICATIONS
5
21"
7-3/4"
10-1/4"
Side View
FLOOR
On Each Side
(installer supplied)
14"
96"
(MIN)
(MIN)
(MIN)
1/2" Conduit
Drip Leg
(installer supplied)
Gas Shut-off
(installer supplied)
Gas Pipe
(installer supplied)
Utilize 2
bolts (min)
per bracket.
Utilize 2
bolts (min)
per bracket.
Surface
Combustible
Valve
Four Bolts Two
