PARTS SUPPLIED
2
If the Drain hoses supplied are not long enough
to reach your services, you must use a Drain Hose
Extension Kit P/N 525798 which will extend the drain
hoses by 11’ 10” (3.6m).
The kit is available from the nearest DCS by Fisher
& Paykel Authorized Service Center, or Toll free
1.888.936.7872 or www.dcsappliances.com
Wire clip (2)
(for securing
Drain hose joiner)
Phillips
⁄” (16 mm)
screws (9)
Drain hose
support (1)
Moisture protection
tape (1)
(to prevent moisture
damage)
Drain hose
joiner (1)
Top
mounting
brackets (2)
OPTIONAL
Prefinished toekick (1)
Hexagonal
socket for feet
adjustment (2)
(long & short)
Side mounting
bracket kit
(A and B) (2)
OPTIONAL
Edge Protector (1)
(If the services hole is through
a metal partition the hole
must be protected with the
Edge protector supplied to
prevent damage to the power
cord or hoses.)
Clamp (1)
(for securing
Drain hose joiner)
Rubber
washer for
inlet hose (1)
(comes already
fitted)
