13
9b
REMOVE THE LOWER DRAWER
100 mm
2
4
5
1
To prevent kinked hoses, we recommend
rotating the drawer counter-clockwise and
resting it on its side after removal.
Press the release tabs in on either
side and push back to release
drawer from runners.
Push drawer runners back in.
8b
PULL THROUGH HOSES & PUSH INTO THE CAVITY
(x2)
optionally attach the
two top mounting brackets
You can initially level the product
You can raise or lower the
product by twisting the
feet. Then take care when
pushing the product into
the cavity that you do not
bend the feet.
ALTERNATIVE METHOD (b) - SECURE BY DRAWER REMOVAL
As you push product in, pull
through hoses and cord,
ensuring they don’t get
kinked or twisted.
4” (100mm)
3
4
