DCS US CA - Product Dimensions

6
H
K
M
NA
O
O
I
Side
Plan
G
F
J
L
B
C
E
D
4
PRODUCT DIMENSIONS
Product dimensions inches (mm)
DD24DUT7
DD24DVT7
A
overall height
1
of product 34 - 36 ⁄”(864-924)
2
34 - 36 ⁄”(864-924)
2
B
overall width of product 23 ⁄”(605) 23 ⁄”(605)
C
overall depth of product (excl. handle) 22 ⁄”(577) 22 ⁄”(577)
D
depth of chassis (to back of front panel) 21 ¾ ”(553) 21 ¾ ”(553)
E
maximum extension of drawer (excl. handle) 21 ¾ ”(552) 21 ¾ ”(552)
F
depth of front panel (excl. handle) 1”(25) 1”(25)
G
height
1
of chassis 33 ⁄”(855) 33 ⁄”(855)
H
height of levelling feet ⁄ - 2 ⁄”(9-69)
2
⁄ - 2 ⁄”(9-69)
2
I
depth of handle 2 ⁄”(66) 2 ⁄”(60)
J
depth of toekick recess (to back of front panel)
3
1 ⁄ - 3 ⁄”(30-92) 1 ⁄ - 3 ⁄”(30-92)
K
height of upper front panel 17 ⁄”(442) 17 ⁄”(442)
L
ventilation gap between front panels ⁄”(8) ⁄”(8)
M
height of toekick panel (adjustable) 2 ¾ - 4 ¾ ”(70-120)2 ¾ - 4 ¾ ”(70-120)
N
height of drawer fronts 29 ⁄”(760) 29 ⁄”(760)
O
height from top of handle to top of front panel 2 ⁄”(62) 2 ⁄”(62)
1
includes ⁄” (2mm) high bracket slots
2
depending on adjustment of leveling feet
3
adjustable to match toekick recess on adjoining cabinetry
