ddrum BETA XP - Drum Components and Connectivity

6
HI-HAT
SNARE
TOM1
CYMBAL1
H.H. CTRL
BASS CTRL
LINE IN
OUTPUT (STEREO)
PHONES
1
3
4
5
6
2
4 CY M BAL1
5 H.H. CTRL
controller only
optional
controller only
6 BASS CTRL
LINE IN
PHONES
2 SNARE
3 TOM1
1 HI- HAT
mobile
phone
music
player
!
1 2 4 7
must use Stereo Sound Cables
(two black lines)
1/4"(6.35mm) Stereo
Stereo
Stereo
1/4"(6.35mm) Mono
Mono
Mono
3.5mm Stereo
3.5mm Stereo
