6 / 14
4~20mA DC（with HART protocol）
See load characteristics chart (Figure 2)
M20×1.5 (female thread) or on request
Intrinsic safety type Ex ia ⅡC T1～T5/T6 Ga
Explosion-proof type Ex d ⅡC T1～T5/T6 Gb
Figure 2 Load Characteristics Chart
4 Dimension Schematic-Figure 3
If special dimensions are required when ordering, the actual dimensions shall prevail.
Figure 3
