9
CAUTION!!! High sound pressure can damage your health!
Please use the common sense when controlling volume!
2+2 Ohm
4+4 Ohm
0.5 Ohm
0. 5 Ohm2
1+1 Ohm
0.125 Ohm
Voice coils
Total impedance
7. SP E CI F ICATI ONS
EN
Power RMS 4 Ohm* (W)
Power RMS 2 Ohm* (W)
Model
Crossover (dB/Oct)
Subsonic (Hz)
Bass level adjustment (dB)
Frequency response (Hz)
Input sensitivity (V)
Signal to noise ratio (dB)
Damping factor
205
331
AAB-500.1D
568
15 - 50
0 - 12
15 - 180
0.2 - 6
Power RMS 1 Ohm* (W)
Power RMS 1 Ohm** (W)
502
12
45
Bass frequency adjustment (Hz)
Input terminal connection (AWG / mm²)
Output terminal connection (AWG / mm²)
Working voltage (V)
Size (WхLхH mm)
The minimum permissible resistance (Ohm)
Size (WхLхH inch)
9 - 15
4 / 21.2
125 x 160 х 63.5
1
4.92 x 6.3 х 2.5
8 / 8.37
*RMS Power at 14.4 V, THD 1%
**RMS Power at 12 V, THD 1%
Low pass filter (Hz)
35 - 180
> 100
> 210
