394
23
Push the air lter pipe as far as
it will go, so that its mouth rests
against the metal of the carburettor (red
dotted line).
24
This stage is complete. Store your parts away securely until next time. The
remaining stickers on the sheet will be applied to the inside rim of the
tyre, so keep these safely until they are needed.
10
12
11
21
Finally, apply stickers 10-12 to the top surface of the helmet cover. Use the yellow
dotted lines shown in the photo above for guidance.
22
If you removed the air lter pipe
in Step 16, re-insert it before
proceeding. Press the wider end of the
pipe over the open intake port of the
carburettor (see red arrow).
