Deagostini Robi - Assembling Robis Head Frames

ASSEMBLING THE FRAMES
1
2
Before you bein, sort out the left and riht head frames. Lay both of
them out on your work surface, facin each other as shown. Compare
them with the photo to ensure that you can tell the left and riht
frames apart. The two are almost symmetrical, but the back of the
left frame is shorter than the equivalent area on the riht.
Take the neck mountin in your riht hand and
oer up the left head frame as shown. Double-
check that you have selected the correct side.
53 4
Place the parts toether so that
the two holes circled in red line up.
Fit one of the M2 x 4.5mm countersunk
screws into each of the holes and
tihten them with the screwdriver. Be
careful not to overtihten the screws.
Now alin the riht head frame
with the neck mountin as
indicated in red, so that the holes
match as they did in Step 3.
!
86 7
Holdin the parts toether, fit two
M2 x 4.5mm countersunk screws
into the circled holes.
Tihten both screws with the
screwdriver.
That completes the assembly of
the head frames. This view from
above shows which way round it
will fit in the head.
Left head frame Right head frame
Short
Long
Left
Front
Back
Right
07
