27
GENESIS-VP™: User’s Manual
Appendix 1, Specifications
Antenna Parameters
K-Band
IACP Type III
Nominal Transmission Frequency 24.150 ±50 MHz
Nominal Horizontal Beamwidth 12°
Polarization Circular
Nominal Microwave Power Output 10 mW
Maximum Aperture Power Density ≤1 mW/cm
2
Environment
Ambient Operating Temperatures -30°C to +70°C
-22°F to +158°F
Maximum Humidity 90% relative humidity at 37°C
(non-condensing)
Water Resistance Meets International Robustness
Standard IEC 529:1989 and
European Community Standard
EN 60529 Classification IP55.
These set international standards
for immunity from damage by
solid protrusions and water.
Voltages
Supply Voltage 5.5 VDC — 8 VDC
Power supplied from replacable
Ni-Cad batteries
Low Voltage Threshold 5.5 VDC
Speed Range Parameters
Speed Display Ranges Minimum Maximum
Target: mph Option 5 200
kph Option 8 320
