MG3 & MG4 | V1 | Page 4
ASSEMBLY: CENTER VERT + CABSIDE VERT
NOTE: Perform the next few steps on a flat surface like a garage floor.
• Attach center vert to cabside vert with four bolts. Alternate to tighten; BAG S1.
CENTER VERT
CABSIDE VERT
S1
PLACE HOOK ON CENTER VERT
OVER NOTCH IN CABSIDE VERT
HELPFUL TIP: BAG S1, a.k.a "Bunker Hill," is required
for most of the steps, so keep it close! These bolts are
highlighted throughout instructions in RED.
To Next Page
