MG3 & MG4 | V1 | Page 5
ASSEMBLY: LOOSELY ATTACH STUDS (YUP)
• LOOSELY attach studs to cabside vert with six bolts; BAG S1.
CENTER VERT
PASSENGER
SIDE STUD
CABSIDE VERT
DRIVER
SIDE STUD
KEEP LOOSE
(YOGA HELPS)
S1
KEEP LOOSE
S1
