Part 5: Stand Installation
Keep the foam underneath the monitor before attaching the stand.
1. Open the package, take out the product with foam still attached, and gently place it on a
desktop or table.
2. Lock the base and stem with three screws.
3. Take out the monitor and remove the bottom foam section.
4. Align the stand stem’s bracket with the opening on the back of the monitor. and carefully
insert bracket. The pieces should click into place.
Stem
Base
Screws (12 mm x3)
To Next Page
