EN
19
Neutral
Phase
N
L
Green/yellow
Blue
Brown
•
220-240 V monophase hook-up
Ground
Blue
Brown
Green/yellow
Ground
Phase
L
32 A
32 A
Green/yellow
Blue
Brown
Terre
Blue
Brown
Green/yellow
Neutre
N
Phase
L
32
amp fuses.
63
amp fuse.
Neutral
N
Connection DTI743
1 / INSTALLING YOUR APPLIANCE
•
Hook-up of 220-240V
~
Warning
If the cable is damaged it must be
replaced by the manufacturer, its after-
sales service or a person with a similar
qualification to prevent danger.
These hobs must be connected to the mains using a socket in compliance with publication CEI
60083 or an all-pole circuit-breaker device in compliance with the installation rules in force.
When power is first supplied to your hob, or after an extended power cut, an indicator light will
appear on the control panel. This information will disappear after 30 seconds.
Connection
N
L
Green/yellow
Blue
Brown
32A
EarthNeutral Phase
Connection DTI749
