SP301-C
1
WHAT IS INCLUDED
FEATURES
1 Indoor/Outdoor
Night Vision CCD Color
Camera
2 Window
Security Stickers
4 PIN DIN to RCA (male)
Video/Power Wire
BNC to RCA Connector
1 Power Adapter for Camera
Mounting Hardware
Instruction Manual
1 Year Warranty
Online/Toll Free Support
Table of Contents
WHAT IS INCLUDED ...................................................................................................................................1
FEATURES .................................................................................................................................................1
CAMERA INSTALLATION ............................................................................................................................2
MOUNTING THE CAMERA ........................................................................................................................2
CONNECTING THE CAMERA .....................................................................................................................2
TROUBLE SHOOTING ................................................................................................................................3
SPECIFICATIONS ......................................................................................................................................4
NOTES ......................................................................................................................................................5
DRILLING TEMPLATE ...............................................................................................................................6
SP301-C Camera
1. Sun Shield: Helps prevent glare from bright lights
2. Infrared (IR): LEDs Allows the camera to see in the dark
up to 15ft away.
3. CDS Sensor: Automatically turns on the infrared LEDs
when it gets dark
4. Camera Housing
5. Camera Mount
6. 4 PIN DIN Female Connection
IMPORTANT INFORMATION
While this camera is weatherproof, it is not waterproof.
Please do not install it in areas that receive direct rain or
under eaves trough draining spots. Do not cut the DC power
cable of this camera to t with another power source. Do not
cut the video connection wire to t with a dierent video
connection type. Any unauthorized modications will void
your warranty.
