IR Remote Control Function and Data List
W Studio Micro’s remote control codes are discrete IR (Infrared) codes. Custom installers may want to have access to the standard
codes that enable the W Studio Micro’s remote functions to be programmed into a universal controller. Below are the remote control
function and data lists for these functions:
IR Remote Control Function and Data list for the W Studio Micro Sound Bar
Standard Codes
NEC Transmission Format using Denitive Technology Custom Code (A): 0x0A56
Custom Code Data Code
BUTTON Screen Print FUNCTION: W Studio DECIMAL Ccode Ccode’ Dcode Dcode’
Power power symbol Power toggle: On / Off (standby) 136 0x0A 0x56 0x88 0x77
Mute mute symbol Power toggle: On/Off (standby) 138 0x0A 0x56 0x8A 0x75
SRC1 Select: Source ‘Input 1’ 150 0x0A 0x56 0x96 0x69
SRC2 Select: Source ‘Input 2’ 151 0x0A 0x56 0x97 0x68
SRC3 Select: Source ‘Input 3’ 152 0x0A 0x56 0x98 0x67
CENTER + CENTER + Center Level: adjust Up (+) 192 0x0A 0x56 0xC0 0x3F
CENTER - - CENTER Center Level: adjust Down (-) 193 0x0A 0x56 0xC1 0x3E
VOLUME + VOLUME + Master Volume: adjust Up (+) 212 0x0A 0x56 0xD4 0x2B
VOLUME - - VOLUME Master Volume: adjust Down (-) 208 0x0A 0x56 0xD0 0x2F
BASS + BASS + Subwoofer Level: adjust Up (+) 214 0x0A 0x56 0xD6 0x29
BASS - - BASS Subwoofer Level: adjust Down (-) 210 0x0A 0x56 0xD2 0x2D
MOVIE MOVIE Select: ‘Movie’ audio DSP
processing mode
140 0x0A 0x56 0x8C 0x73
MUSIC MUSIC Select: ‘Music’ audio DSP
processing mode
141 0x0A 0x56 0x8D 0x72
IR Remote Control Function and Data list for the W Studio Micro Sound Bar
Discrete Codes
NEC Transmission Format using Denitive Technology Custom Code (B): 0x0A58
Custom Code Data Code
NAME FUNCTION: W Studio DECIMAL Ccode Ccode’ Dcode Dcode’
Power ON DISCRETE_POWER_ON 87 0x0A 0x58 0x57 0xA8
Power OFF DISCRETE_POWER_OFF 88 0x0A 0x58 0x58 0xA7
Mute DISCRETE_MUTE 92 0x0A 0x58 0x5C 0x6D
Unmute DISCRETE_UNMUTE 93 0x0A 0x58 0c5D 0xA2
IR codes in Philips Pronto format are available through our customer support group.
Please contact them at info@DenitiveTech.com or 800-228-7148.
Note: When programming a macro for your home automation system, the W Studio Micro can be
powered on with any of the source select remote commands (SRC1, SRC2, SRC3).

Definitive Technology W Studio Micro Specifications

General

Audio Channels	5
Subwoofer	included
Surround Sound	dolby digital
High Resolution Audio	yes
Dialogue Enhancement	yes
Number of Drivers	0
RMS Power	320 watts
Video Pass-through	3d
Tweeters	3
Inputs	3.5mm audio, hdmi, optical
Outputs	none
HDMI Inputs	1
HDMI Outputs	1
HDMI ARC Ports	no
USB Ports	0
Bluetooth	no
Wireless Connectivity	wi-fi
Wireless Subwoofer Connectivity	yes
Wireless Multi-Room Audio	yes
Wireless Multi-Room Technology	definitive technology wireless collection
Optical Audio Inputs	1
Voice Assistant	not applicable
Remote Control	yes

Weight and Dimensions

Depth	3.38 inches
Height	3.3 inches
Width	43 inches
Net Weight	13.7 pounds
Subwoofer Depth	12.77 inches
Subwoofer Height	14.03 inches
Subwoofer Width	12.54 inches
Subwoofer Weight	15 pounds
