MAINTENANCE CONTINUED
CLEANING THE DRAIN FILTER
Place a shallow con-
tainer under the drain-
filter to collect any
residual water spillage.
Turn the filter cap in an
anticlockwise direction.
Pull the filter assembly
out.
Clean the drain filter.
Re-fit the filter along the
guides ensuring that
the groove in the filter
aligns with the guide rib.
Tighten the cap by turn-
ing it in a clockwise
direction.
TECHNICAL SPECIFICATIONS
Dry weight capacity 8.5 kg.
Power source AC 220-240V / 50 Hz
Power consumption 430 W
Dimensions ( W x H x D ) in mm. 598 x 956 x 643
Unit weight 43kg
Standard water consumption 207 litres
Water level for High, Medium, Low, Small 88, 75, 61, 48 litres
Wash mode Double action type Air bubble + Pulsator.
