Page 12
The Place where the external filter is going
to be fitted should first be determined.
(Applies to the filter being used outside the
refrigerator.) Then, determine the distance
between the filter and the refrigerator and
required hose lengths from the filter to the
refrigerator water inlet.
The water filter must be held upright as
shown in the figure. It is important to attach
the filter properly to the water inlet and water
outlet points.
After attaching the filter, do not use the first 3
-4 glasses of water.
Installing the Water Filter
(in some models)
Installation Requirements
Two different water sources may be
connected to the refrigerator for the water
supply: the mains cold water supply and
water in a jug.
A pump should be used for water jug usage.
Check that the parts stated below are
supplied with your refrigerator.
1. Union for connection of the water pipe to
the rear of the refrigerator .
2. 3 pipe clips (if required to secure the water
pipe).
Note:
Since the following parts are not required to
be used with a jug, they may not be found in
the refrigerator you have purchased.
3. 5 meter long water pipe (1/4 inch in
diameter)
4. Cold mains water valve with mesh filter
(Tap Adapter)
5. Water Filter to be fitted to the bracket
inside the fridge compartment.
4
