36BB, 36BDB
BRUSH BEAST
6
Rev: Mar2011
BRUSH BEAST Brush Mower
Step 1: Front Assist Wheel Assembly
The mower is shipped in a steel shipping rack (see
adjacent photo). Note: Some mowers are shipped with
the front wheels pre-assembled.
A. Remove the rack by removing the front mounting
bolt.
B. Remove packaging materials surrounding the front
skid wheel and remove the bolt. Retain the bolt,
spacer, nut and bushing for future use.
C. Remove the fastener holding the bolt to the steel
shipping rack. Retain the nut and bolt for future use
in the mower assembly process.
D. Remove the mower from the steel shipping rack.
E. Slide the front skid wheel into the mount. Position
the wheel with the spacer toward the center of the
mower and the wheel as close to the deck edge as
possible.
F. Secure the wheel in place with the bolt and
hardware that is provided with the wheel.
G. Follow the same procedure for the second
front skid wheel.
Assembly Instructions
