DeKo DKCSP03 - Product Information; Parts Description; Specifications; Intended Use

2
Parts Description
1. Power cable
2. Handle
3. Output hose fitting ( GHT 3/4", NPT 1-1/4" From up to down)
4. Pump base
Specifications
Model
DKCSP03/DKCSP03BL
CSP9026/CSP9028
DKCSP04/DKCSP04BL
CSP9025/CSP9027
Rated Voltage
100-120V~50/60Hz
100-120V~50/60Hz
Power
1/3HP
1/4HP
Amps
3.5 Amp
3 Amp
Q.max (Max. Flow Rate)
2450GPH
1850 GPH
H.Max (Max. Lift Height)
28ft (8.5m)
27 ft (8m)
Max. Submersion Depth
23.0ft (7m)
23.0ft (7m)
Max. Grain Size
1/8” (3.2mm)
1/8” (3.2mm)
Power Cord Length
10 ft (3m)
10 ft (3m)
Diameter of Pipe
GHT 3/4", NPT 1-1/4"(From
Up to Down)
GHT 3/4", NPT 1-1/4"(From Up
to Down)
Max. Water Temperature
95°F (35°C)
95°F (35°C)
Waterproof Class
IPX8
IPX8
Remark: for final and correct voltage / frequency info, please refer to the rating label on the
product.
Intended Use
This non-automatic submersible utility pump is designed to remove water from, flooded
basements, window wells and stock tanks, etc.
