Del ozone Eclipse-1 - Important Safety Instructions; General Safety Precautions; Electrical Safety; Installation and Environmental Safety

Table of Contents
DELZONE
®
Eclipse 1, 2, & 4 Corona Discharge Ozone Generators
SECTION 1
General Information
1A Description ......................................................................... 1
1B Specications .................................................................... 1
1C WarrantySummary .......................................................... 1
SECTION 2
Installation
2A Location .............................................................................. 1
2B Mounting ............................................................................ 1
2C Electrical ............................................................................. 1
2D Plumbing ............................................................................ 2
SECTION 3
Operation
3A General ............................................................................... 2
3B InitialSystemStart-Up ..................................................... 2
3C NormalOperation ............................................................. 2
3D SystemShut-Down ............................................................ 3
3E WaterChemistry ............................................................... 3
SECTION 4
Maintenance & Service
4A SystemElectro-MechanicalOverview ............................ 3
4B SystemMaintenance ........................................................ 3
4C GeneratorServicing .......................................................... 3
4D TroubleShooting ............................................................... 4
SECTION 5
Replacement Parts and Ordering
Information
5A OrderingInformation ........................................................ 5
5B StandardReplacementPartsList .................................. 5
Warranty .....................................................................5
IMPORTANT SAFETY INSTRUCTIONS
Read and Follow All Instructions
• Read this manual completely before attempting installation.
•Allpermanentelectricalconnectionsshouldbemadebyaqualiedelectrician.
• For cord and plug-connected units, connect to a grounded, grounding type receptacle only. If the DELZONE
®
Eclipse electrical connection is to
be attached to the pool controls, be sure the pool controls are protected by a Ground Fault Circuit Interrupter (G.F.C.I.). If the DELZONE
®
Eclipse
is connected to an independent electrical supply, then a G.F.C.I. must be installed between the DELZONE
®
Eclipse and the electrical supply.
• Do not bury cord.
• Warning - To reduce the risk of electrical shock, replace damaged cord immediately.
• A pressure wire connector is provided on the outside of the unit to permit connection to a minimum No. 8 AWG (8.4 mm
2
) solid bond-
ing conductor between this point and any metal equipment, metal enclosures of electrical equipment, metal water pipes, or conduit
withinve(5)feet(1.5m)oftheunitasneededtocomplywithlocalrequirements.
• Install at least 5 feet (1.5 meters) from wall of pool water using nonmetallic tubing. Install ozone generator no less than one (1) foot
above maximum water level to prevent water from contacting electrical equipment. Install in accordance with the installation instruc-
tions.
• Follow all applicable electrical codes.
• Electric shock hazard. Be sure to turn power OFF and disconnect from power source before any service work is performed. Failure to
do so could result in serious injury or death.
• The DELZONE
®
Eclipse must be installed in an outdoor location, or indoors in a forced air ventilated room, and installed so that the
orientation is exactly as shown in Figure 1. Install to provide water drainage of generator to protect electrical components.
• Mount the DELZONE
®
Eclipse so that it is inaccessible to anyone in the pool. Never attempt any servicing while unit is wet.
• Plastic ozone supply tubing is supplied with the Eclipse. Never replace this tubing with metal tubing.
• Warning - Short-term inhalation of high concentrations of ozone and long term inhalation of low concentrations of ozone can cause
serious harmful physiological effects. DO NOT inhale ozone gas produced by this device.
•Foryoursafety,donotstoreorusegasoline,chemicalsorotherammableliquidsorvaporsnearthisoranyotherappliance.
SAVE THESE INSTRUCTIONS!
