Delaney KP300 - Latch Backset Adjustment

2
Machine Screws
Qty. 3
Wood Screws
Qty. 5
Deadbolt Chassis Screws Qty. 2
J K
L
HARDWARE SCREWS CONTENTS
LATCH BACKSET ADJUSTMENT
Remarks:
Please notice the the latch box between two different backsets.slight differences in
180°
2 3/4" (70 mm)2 3/8" (60 mm)
70 mm
60 mm
