Delem
V0802, 5.5
Parameter 28: Position measurement system
Range : 0 - 1
Default : 0
Units : -
Function
To select the position measurement system of the axis.
Description
You can select for each axis two types of position measurement systems.
0 = encoder
1 = potentiometer
Press the key to select the required setting.
Encoder position measurement
The value of this parameter has also consequences for the use of other parameters.
When you have the encoder position measurement, then you can program the following
parameters:
Pre scaling.................................... 9
Reference position........................ 5
Ref. search direction..................... 6
RSD switch mounted.................... 17
Reference search speed................. 21
Potentiometer position measurement
When you have the potentiometer position measurement you have instead of parameters 9, 5, 6,
17 and 21 the following parameters to program:
AD-min......................................... 29
AD-max........................................ 30
