Delem
V0802, 3.1
Parameter 1: Service row 1/0
Range : 0-1
Default : 0
Units : -
Function
To display the actual Y-axis linear scale readings, status and cycle numbers on the screen. There
are two possibilities:
1 = Service row present
0 = Service row not present
Press the key to select the required setting.
Description
The service row is displayed on the upper row of the screen. When switched on the actual Y-axis
linear scale readings, the status and cycle numbers are displayed on the screen.
On the control the following line is displayed.
Y1 = 123.15 Y2 = 123.21 status= 1 cyclus = 0 Idle
The service row contains 5 information fields:
Y1 = left side linear scale reading
Y2 = right side linear scale reading
Status = status number
Cyclus = cycle number
Idle = communication information
