Dell 1220 - Page 46

46 Specifications
Noise Level Normal mode: 34 dB(A) Typical
Eco mode: 31 dB(A) Typical
Weight 5.4 lbs (2.4 kg)
Dimensions (W x H x D)
12.38 x 3.45 x 8.8 inches (314.4 x 87.6 x 223.5 mm)
Environmental Operating temperature: 5 °C - 40 °C (41 °F- 104 °F)
Humidity: 80% maximum
Storage temperature: 0 °C to 60 °C
(32 °F to 140 °F)
Humidity: 90% maximum
Shipping temperature: -20 °C to 60 °C
(-4 °F to 140 °F)
Humidity: 90% maximum
I/O Connectors Power: One AC power socket (3-pin - C14 inlet)
VGA input: One 15-pin D-sub connector (Blue),
VGA In, for analog RGB/Component input signal.
VGA output: One 15-pin D-sub connector
(Black) for VGA In loop through.
HDMI input: One HDMI connector for support
minimum HDMI 1.4a specification HDCP
compliant.
Composite Video input: One Yellow RCA jack for
CVBS signal.
Analog Audio input: One 3.5 mm stereo mini
phone jack (Blue).
Variable Audio output: One 3.5 mm stereo mini
phone jack (Green).
3.45"(87.6 mm)
12.38"(314.4 mm)
8.8"(223.5 mm)
