Dell 1320 - Page 4

15 power and battery charge status lights 16 keyboard
17 power button 18 device status lights
19 keyboard status lights 20 display
1 wireless switch 2 ExpressCard/54 slot
3 USB connectors (2) 4 cooling vents
5 AC Adapter connector 6 network connector
7 VGA connector 8 battery
1
2
3
4
5
6
7
8
X951Mam0.fm Page 4 Tuesday, March 24, 2009 11:19 AM
