Vostro 1720
1 latches (2) 2 microphone (optional)
3 camera light (optional) 4 camera (optional)
5 keyboard status lights 6 media control button (volume,
forward, reverse, stop, play, and
mute)
7 security lock 8 optical drive/media bay
9 USB connectors (2) 10 IEEE 1394 connector
11 wireless switch 12 fingerprint reader (optional)
13 touch pad 14 touch pad buttons
15 8-in-1 card reader 16 audio connectors
