16 Adjusting Projector Image
Adjusting Image Shape
1550
Projection
Distance
(m)
[A]
Min Zoom
Image size
Projector base to
top of image (cm)
[C]
Projector base to
bottom of image
(cm)
[D]
Diagonal
(inch/cm)
[B]
Width (cm)
[W]
Height (cm)
[H]
1.2 30.7"/77.98 cm 63 47 54 7
3 77"/195.58 cm 156 117 135 18
5 128"/325.12 cm 260 195 225 30
7 179"/454.66 cm 365 273 314 41
9 231"/586.74 cm 469 352 404 52
10 256.3"/651 cm 521 391 449 58
Projection
Distance
(m)
[A]
Max Zoom
Image size
Projector base to
top of image (cm)
[C]
Projector base to
bottom of image
(cm)
[D]
Diagonal (inch/cm)
[B]
Width (cm)
[W]
Height (cm)
[H]
1.2 36.9"/93.73 cm 75 56 65 9
3 92"/236.22 cm 188 141 162 21
5 154"/391.16 cm 313 234 270 36
7215"/546.1 cm438 328 377 49
9 277"/703.58 cm 563 422 485 63
10 307.5"/781.05 cm 625 469 539 70
* This graph is for user reference only.
* Offset Ratio: 115±5%
