Dell 1550 - Page 17

Adjusting Projector Image 17
1650
Projection
Distance
(m)
[A]
Min Zoom
Image size
Projector base to
top of image (cm)
[C]
Projector base to
bottom of image
(cm)
[D]
Diagonal
(inch/cm)
[B]
Width (cm)
[W]
Height (cm)
[H]
1.2 36.2"/91.95 cm 78 49 55 6
3 91"/231.14 cm 195 122 137 15
5 151"/383.54 cm 326 203 229 26
7 212"/538.48 cm 456 285 320 35
9 272"/690.88 cm 586 366 412 46
10 302.2"/767.59 cm 651 407 457 50
Projection
Distance
(m)
[A]
Max Zoom
Image size
Projector base to
top of image (cm)
[C]
Projector base to
bottom of image
(cm)
[D]
Diagonal (inch/cm)
[B]
Width (cm)
[W]
Height (cm)
[H]
1.2 43.5"/110.49 cm 94 59 66 7
3 109"/276.86 cm 234 146 165 19
5181"/459.74 cm391 244 274 30
7 254"/645.16 cm 547 342 384 42
9326"/828.04 cm703 439 494 55
10 362.7"/921.26 cm 781 488 549 61
* This graph is for user reference only.
* Offset Ratio: 112.4±5%
