Dell 2000FP - Page 17

Dell 2000FP LCD Monitor Service Guide
Engineering Specification
Confidential
17
1 Max Horiz size cm 29 40.8 cm
1 Max Vert size cm 1F 30.6 cm
1 Gamma Value 96 Gamma=2.5
1 Feature Support EB standby/suspend/off
preferred timing
default GTF supported
Color
Characteristics
10 R,G,B 4C,40,A1,57,4C,
97,26,1C,50,54
x
R
=0.63 y
R
=0.34 x
G
=0.30 y
G
=0.59
x
B
=0.15 y
B
=0.11 x
W
=0.313 y
W
=0.329
720×400 @ 70: Y
720×400 @ 88: N
640×480 @ 60: Y
640×480 @ 67: N
640×480 @ 72: N
640×480 @ 75: Y
800×600 @ 56: N
1 Timing I A5
800×600 @ 60: Y
800×600 @ 72: N
800×600 @ 75: Y
832×624 @ 75: N
1024×768 @ 87: N
1024×768 @ 60: Y
1024×768 @ 70: N
1024×768 @ 75: Y
1 Timing II 4B
1280×1024 @ 75: Y
Established
Timings
1 Mfg. reserved 00 Not used
2 ID #1 81,80 1280×1024,60Hz
2 ID #2 A9,40 1600×1200,60Hz
Standard
timing
10 ID # 3,4,5, 6, 7, and 8 01,01,01,01,01,01,
01,01,01,01,01,01
Unused
Detailed
Timing
Description
18 Detailed Timing
(Preferred timing mode)
48,3F,40,30,62,B0,32,40,40,
C0,13,00,6F,13,11,00,00,1E
1600×1200,60Hz
Monitor
Descriptor
18 Serial No 00,00,00,FF,00,30,30,33,30,50
,39,37,52,31,32,33,34,0A
Serial No.
0030P - 97R - 1234
18 Monitor Name 00,00,00,FC,00,44,
45,4C,4C,20,32,30,
30,30,46,50,0A,20
“DELL 2000FP”
18 Range Limit 00,00,00,FD,00,38,
4C,1F,50,10,00,0A,
20,20,20,20,20,20
V range 56-76Hz
H range 31-80kHz
Max pixel clk 162Mhz
Extension Flag 1 00
Check sum 1 00 (varies)
