Dell 2000FP LCD Monitor Service Guide
Engineering Specification
Confidential
18
Appendix 8 – Power State Maximums
CUP
State
Monitor
State
Maximum
Power
Maximum Recovery
time
LED State
ON Active 60W -- Green
Stand-by Sleep 5W Amber
Suspend Sleep 5W Amber
OFF Sleep 5W Amber
Appendix 9 – LCD Module Specification
ITEMS LG.PHILIPS LM201U1-A1
Diagonal size 20.1 inches (51 cm)
Pixel arrangement 1600×1200×R,G,B
Display mode Normally black IPS
Viewing angle technology Wide view angle
Natural color depth 24 bits
Input I/F TMDS
External dimensions 467.8(W)×361.0(H)×32.0(D)
Surface treatment Hard coating 3H, Anti-glare treatment
Backlight Operating Lifetime
(Brightness=50%)
30,000Hrs (min)
Maximum starting time
Under operation conditions
2 sec
Appendix 10 – Mechanical Specification
All plastics Resin
ITEMS Specification
Material GEC2800/Bayer FR2000/CHIEL NH-1000T
Texture ACM standard
UV <1
Heat Defection Temp.
80°C
Flame Retardant Pkg Triarylphosphate esters
Flammability V0
Color Midnight gray/Pearl white
Mechanical Assembly
ITEMS Specification
Gap LCD Panel/bezel gap<1.2mm
Gap front/rear cover 0.5<gap<1.5mm
Gap between other plastic parts <1.0mm
Step in the same plastic <0.5mm
Step between different plastics <0.8mm
LCD module centering Viewable area cannot be hidden by the front bezel
