Soundbar Attachment to the Monitor

Back to Contents Page
1.
Attach mechanism
2.
Headphone connectors
3.
Power indicator
4.
Power/Volume control
NOTE:Soundbar Power Connector - 12V DC output is for optional Dell Soundbar only.
NOTICE: Do not use with any device other than Dell Soundbar.
1.
Working from the rear of the monitor, attach Soundbar by aligning the two slots with the two tabs along the bottom rear of the monitor.
2.
Slide the Soundbar to the left until it snaps into place.
3.
Connect the Soundbar with the DC power connector.
4.
Insert the mini stereo plug from the rear of the Soundbar into the computer's audio output jack.
