120 Installing System Components
Figure 3-17. Installing or Removing Expansion-Card Riser 1
1 blue tab 2 expansion-card riser 1
3 integrated storage controller card
connector
4 expansion-card slot 1
5 expansion-card slot 2 6 riser guide pin
7 riser 1 connector on system board 8 riser guide
2
5
6
7
4
3
8
1
