Expansion-Card Riser-Board Components and
PCIe Buses
Figure 6-4. PCIe Expansion-Card Riser 1 Components
1 slot 1 PCIe - x8 link expansion slot
(24.13 cm [9.5"] length)
2 slot 2 PCIe - x4 link expansion slot
(low-profile 24.13 cm [9.5"] maximum
length, with a standard height
bracket)
3 integrated storage controller card
connector
3
1
2
