Installing System Components 127
Figure 3-20. Installing the Integrated Storage Controller Card
1 expansion card riser 1 2 SAS data cable connectors (2)
3 SAS data cables (2) 4 integrated storage controller card
5 alignment guides (2) 6 integrated storage controller card
connector
6
1
4
5
2
3
