82 Installing System Components
Figure 3-1. Inside the System
1 cooling shroud 2 power supply bays (2)
3 expansion-card riser 2 4 expansion-card riser 1
5 heat sinks (4) 6 memory modules (32)
7 hard drives (6) 8 control panel
9 optical drive (optional) 10 cooling fans (6)
11 cooling fan assembly 12 internal dual SD module
