Dell Alienware 17 R5 Setup And Specifications

Table 15. Video specifications (continued)
Integrated Discrete
NOTE: The NVIDIA graphics cards
support G-Sync panels.
Memory Shared system memory
● 6 GB GDDR5
● 8 GB GDDR5
● 8 GB GDDR5X
Power adapter
Table 16. Power adapter specifications
180 W 240 W 330 W
Input current (maximum) 2.34 A 3.50 A 4.40 A
Output current
(continuous)
9.23 A 12.31 A 16.92 A
Diameter (connector) 7.40 mm
Input voltage 100 VAC–240 VAC
Input frequency 50 Hz–60 Hz
Rated output voltage 19.50 VDC
Temperature range:
Operating 0°C to 40°C (32°F to 104°F)
Storage –40°C to 70°C (–40°F to 158°F)
Display
Table 17. Display specifications
17.3-inch FHD Anti-Glare
panel
17.3-inch QHD Anti-Glare
panel
17.3-inch UHD Anti-Glare
panel
Resolution (maximum) 1920 x 1080 2560 x 1440 3840 x 2160
Operating angle 140 degrees 140 degrees 140 degrees
Pixel pitch 0.1989 mm 0.14925 mm 0.0995 mm
Dimensions: (excluding bezel)
Height 214.81 mm
(8.46 in)
214.92 mm
(8.46 in)
214.94 mm
(8.46 in)
Width 381.89 mm
(15.04 in)
382.08 mm
(15.04 in)
382.12 mm
(15.04 in)
Diagonal 438.16 mm
(17.25 in)
438.38 mm
(17.26 in)
438.42 mm
(17.26 in)
Refresh rate 60 Hz 120 Hz 60 Hz
G-sync support Yes (optional) Yes Yes
Tobii Eye-tracking support No Yes Yes
15

Dell Alienware 17 R5 Specifications

General

Weight	4.42 kg (9.74 lbs)
Wireless	Killer 1550 802.11ac 2x2 WiFi and Bluetooth 5.0
Processor	Intel Core i7-8750H or i9-8950HK
Graphics	NVIDIA GeForce GTX 1080
Display	17.3 inch FHD (1920 x 1080) 60Hz Anti-Glare IPS
RAM	Up to 32GB DDR4
Storage	1TB HDD
Operating System	Windows 10 Home
Battery	99 Whr Lithium Ion
Ports	1x Thunderbolt 3, 3x USB 3.0, 1x HDMI 2.0, 1x Mini-Display Port, 1x Alienware Graphics Amplifier Port, 1x RJ-45 Ethernet
