Dell D11S Service Manual

3. Install the Side cover.
4. Follow the procedure in After working inside your computer.
Hard drive assembly
Removing the hard drive assembly
1. Follow the procedure in Before working inside your computer.
2. Remove the Side cover.
3. To remove the hard drive assembly:
a) Disconnect the hard drive data cable and power cable from the connectors on the hard drive [1, 2].
b) Push the release tab and lift the hard drive assembly from the system [3].
Removing and Installing components
25

Dell D11S Specifications

General

Network	Gigabit Ethernet
Graphics	Intel GMA 3000
Optical Drive	DVD-ROM
USB Ports	8
Hard Drive	80 GB - 500 GB SATA
