Intel Optane memory
Intel Optane memory functions only as a storage accelerator. It neither replaces nor adds to the memory (RAM) installed on
your computer.
NOTE: Intel Optane memory is supported on computers that meet the following requirements:
● 7
th
Generation or higher Intel Core i3/i5/i7 processor
● Windows 10 64-bit version or higher (Anniversary Update)
● Latest version of Intel Rapid Storage Technology driver
● UEFI boot mode configuration
Table 6. Intel Optane memory
Description Values
Type
Memory/Storage/Storage accelerator
Interface
Gen 3 PCIe x4 NVMe
Connector
M.2 2280
Configurations supported
16 GB and 32 GB
Capacity
Up to 32 GB
Ports and connectors
Table 7. Ports and connectors
Description Values
External:
Network
One RJ-45 port 10/100/1000 Mbps (rear)
USB
● One USB 2.0 port with PowerShare (front)
● One USB 3.2 Gen 2 Type-A port (front)
● One USB 3.2 Gen 2 Type-C port (front)
● One USB 2.0 port (front)
● Three USB 3.2 Gen 1 Type-A ports (rear)
● One USB 3.2 Gen 2 Type-A port (rear)
● Two USB 2.0 ports with Smart Power On (rear)
● One USB 3.2 Gen 2 Type-C Alt-Mode (rear) (optional)
Audio
● One Universal Audio Jack (front)
● One Line-out audio port with re-tasking to Line-in(rear)
Video
● Two DisplayPort 1.4 ports (rear)
● One VGA Port/DisplayPort 1.4 Port/HDMI 2.0b Port/ USB
3.2 Gen2 Type-C Port with Alt-mode (optional)
Memory card reader
One SD 4.0 (optional)
Power port
4.50 mm x 2.90 mm DC-in
Parallel/Serial port One Serial port
PS/2 port Two
Technical specifications 17
