80 Adding Parts
www.dell.com | support.dell.com
Card Installation
1 To add or replace the card, gently press it down into the slot connector
until it clicks into place.
2 Release the card clip lever, ensuring that the tab on the card clip lever
fits into the notch on the front end of the card.
3 Secure the card by lowering the hinged lever on the back panel.
4 Close the computer cover (see page 83).
NOTICE: To connect a network cable, first plug the cable into the network
wall jack and then plug it into the computer.
5
Connect your computer and devices to electrical outlets, and turn
them on.
CAUTION: Before you begin any of the procedures in this section,
follow the safety instructions on page 9.
CAUTION: To guard against electrical shock, always unplug your
computer from the electrical outlet before opening the cover.
card clip
lever
AGP card
card clip
slot connector
