6. Pull up on the drive release latch and slide the Media Card Reader toward the back of the computer. Then, lift to remove the drive from the computer.
Installing a Media Card Reader
1. Follow the procedures in "Before You Begin."
2. Remove the computer cover.
3. Remove the Media Card Reader from its packaging and ensure that all the screws are included.
4. Slide the drive into place until you feel a click or feel the drive securely installed.
