70 Removing and Installing Parts
www.dell.com | support.dell.com
4 Remove the front-panel insert above the door bay area by pulling the bottom of the insert
with your fingers.
5 Lift both hinge arms to the horizontal position.
6 Use the two view slots to align the pivot bar with the two pivot-bar slots.
front-panel
insert
use fingers
to pull here
