Removing and Installing Parts 71
NOTICE: Before touching anything inside your computer, ground yourself by touching an unpainted
metal surface, such as the metal at the back of the computer. While you work, periodically touch an
unpainted metal surface to dissipate any static electricity that could harm internal components.
7
Pull the arms toward you until they snap into position.
If the hinge arms do not snap back into position on the first attempt, slightly reposition the
arms and try again.
8
After the hinge arms snap into position, lower and raise the arms two or three times to
properly seat them.
9
Reattach the front-panel insert.
10
Reconnect the computer power cable to the electrical outlet.
11
Reattach the front door (see page 72).
hinge arms (2)
in horizontal
position
pivot bar
view slots (2)
pivot-bar slots (2)
