Removing and Installing Parts 69
PCI Cards
If you are installing or replacing a card, follow the procedures in the next section. If you are
removing but not replacing a card, see ""Removing a PCI Card" on page 72".
If you are replacing a card, remove the current driver for the card from the operating system.
If you are installing or replacing a PCI Express card, see "Installing a PCI Express Card" on page 74.
Installing a PCI Card
NOTE: Dell offers an optional customer kit for Audigy II and IEEE 1394 PCI add-in-cards that includes a
front-mounted IEEE 1394 connector.
1
Follow the procedures in "Before You Begin" on page 55.
2
Remove the computer cover (see page 60).
card retention
door
release tabs (2)
filler bracket
alignment guide
alignment bar
